NORTH CHESTERFIELD, VA., – -(Ammoland.com)- Carl Zeiss Sports Optics, the world’s leading manufacturer of high performance sports optics, is pleased to announce the world’s first premium crossbow scope, TERRA 3x XB75 with patented ballistic reticle.
The new XB75 2-7×32 offers crossbow enthusiasts the ability to determine aiming points from 20 – 75 yards in 2 ½ yard increments based on the chronographed speed of the bow.
The TERRA XB75 2-7×32 features all the benefits of German engineering and performance that you’ve come to expect from ZEISS, including uncompromising optical performance, all in a lightweight, extremely rugged, compact 1″ design. Features MC anti-reflective coatings to produces bright, high contrast images eliminating the need for an illuminated reticle. Now you can hunt harder and longer by being able to stay on stand when the last bit of light is being squeezed out of the day.
“This was a much needed product for the hardcore crossbow crowd. Finally an optical device that has caught up to the high-tech crossbows out there. Gone are the days of being stuck with subpar optics for the crossbow enthusiast,” stated Mike Jensen, President of Carl Zeiss Sports Optics.
“ZEISS sets another major milestone by being the first premium optics company to launch a dedicated scope for the crossbow community. Once again, this demonstrates our commitment not only to shooting sports but also to the sport of archery.”
The patented technology of the XB75’s reticle provides the ability to shoot distances up to 75 yards in 2 ½ half yard increments. The scope has six separate crosshairs, the main cross section of each crosshair represents whole yardages (20 to 70 yards). The dot in between each set of crosshairs represents the half yardage marks. The top and bottom of each individual crosshair represents the 2 ½ yard marks. The top of the reticle wire protruding from the bottom of the reticle is the 75 yard indicator mark.
The scope’s ocular ring has engravings representing speeds from 275 fps – 425 fps and magnification from 2x – 7x. To program, simply mount the scope on the rail of the crossbow using high-quality rings, then set a target at 10 yards using the 20 yard (1st crosshair from the top) and shoot until you hit center, then repeat at 20 yards. Once the main 20 yard reticle is sighted in, turn the speed indicator on the ocular to the manufacturers advertised speed (this may vary based on bolt length and weight). Now move the target to 30 yards and sight in using the 30 yard reticle (2nd crosshair from the top). Once the 30 yard crosshair is sighted in, the scope is now calibrated to your crossbow and all of the other aiming points will be correct. Crossbows with speeds over 425 fps and using a lighter arrow combination may require a main crosswire sight-in point of 30 yards instead of the normal 20 yards. This will require calibrating the scope at 40 yards to compensate for the flat trajectory of the crossbow bolt. The owner’s manual includes more detailed setup instructions.
TERRA XB75 is built to handle the most rugged terrain and challenging conditions, and is backed by the Carl Zeiss U.S. Limited Lifetime Transferable Warranty.
TERRA XB75 features:
-
Extremely low profile 1 inch tube design
-
2-7x Magnification
-
1/4-MOA adjustments provide 100% repeatability, click by click
-
Patented ballistic reticle with yardages from 20-75 yards
-
For crossbows speeds 275 fps – 425 fps
-
German Engineered
MSRP: $444.43
Technical Data:
2-7×32 | ||
Magnification | 2.3 | 7 |
Effective lens diameter | 24.4 mm | 32 mm |
Exit pupil diameter | 12.2 mm | 4.6 mm |
Twilight factor | 7 | 15 |
Field of view (ft. at 100 yards) | 46.5 ft. | 13.5 ft. |
Objective viewing angle | 7.4° | 2.5° |
Diopter adjustment range | ± 2.5 dpt | |
Eye relief | 90 mm / 3.55 mm | |
Parallax-free | 100 yds. / 30 yds. | |
Square adjustment range | 62 MOA | |
Adjustment per click | 1/4 MOA | |
Center tube diameter | 25.4 / 1 mm | |
Eyepiece tube diameter | 41 mm | |
Objective tube diameter | 39.5 mm | |
Coating | ZEISS MC | |
Nitrogen filling | Yes | |
Waterproof | 400 mbar | |
Functional temperature range | -13 / +122 °F | |
Length | 11.5 in | |
Weight | 13.4 oz | |
Subject to changes in design and scope of delivery as a result of ongoing technical development. |
For more information on ZEISS’ award winning products please visit us at www.zeiss.com/us/sports-optics.
