AR15 vs AR10 , Is Bigger Really Better? A Look at Big vs Little ARs Downrange

Tom compares the AR15 vs AR10 rifles when shooting at long range, and provides data for what happens to bullets as they travel downrange.

So what are the real differences between "big" and "little" AR rifles at longer range? Let's find out.
So what are the real differences between “big” and “little” AR rifles at longer range? Let's find out.

USA –-(Ammoland.com)- We can all probably agree that AR-type rifles are great for shorter ranges, say zero to a couple hundred yards. But what happens when you start to move out to 400, 600, 800, or even 1,000 yards? Will an AR-15 rifle reach that far with the right ammunition? Does an AR-10 rifle chambered in a larger caliber like .308 or 6.5mm Creedmoor make that much difference?

AR15 vs AR10

Let’s take a closer look using a couple of example rifles. First up is the Aero Precision M4E1 rifle with a 16-inch barrel. As a “big AR” comparison, we brought out a Smith & Wesson Performance Center AR-10 chambered in 6.5mm Creedmoor. Last, as a “classic” AR-10 example, we used a Stag Arms Stag 10S AR-10 chambered in .308 Winchester.

For each rifle, we’ll choose one type of ammo that’s reasonably representative of the caliber for comparisons. We’ll make an exception for the .223 / 5.56 and use a 55-grain “standard” and 77-grain “long-range” option.

Also, keep in mind that the performance numbers here are from my exceptionally low altitude of about 30 feet above sea level. If you live just about anywhere else, your performance numbers will be better, meaning that your thinner air will allow bullets to fly farther faster.

So, when you leave the world of factory labs and special testing barrels, what will those rifles do in real-world conditions? Let’s compare some of the common performance attributes.

The significant difference between the AR-10 and AR-15 when it comes to long-range performance is the cartridge options that open up from the larger (longer) magazine well and bolt structure.
The significant difference between the AR-10 and AR-15 when it comes to long-range performance is the cartridge options that open up from the larger (longer) magazine well and bolt structure.

AR15 vs AR10 Velocity

So what do the big and small AR rifles deliver in terms of velocity, not only at the muzzle but well down range? We used a Shooting Chrony Beta Master Chronograph placed 15 feet in front of the fiery hole to measure the actual velocity and calculated the ddownrange speeds based on the specific bullet type and atmospheric conditions.

Again, since this shooting was done near sea level, if you live in a higher elevation, you’ll likely see that velocity carries significantly farther than what’s shown here.

Muzzle

300

600

1000

American Eagle AR223 55-grain .223 Remington

2,895

1,927

1,224

872

Norma Match-223 77-grain .223 Remington

2,472

1,816

1,302

960

American Eagle Open Tip Match 140-grain 6.5mm Creedmoor

2,559

2,068

1,640

1,203

Sig Sauer Open Tip Match 168-grain .308 Winchester

2,450

1,861

1,370

1,002

AR15 vs AR10 Energy

Kinetic energy is dependent on bullet weight and velocity. The velocity component is where things get tricky. Heavier or lighter bullets don’t necessarily carry velocity down range better or worse depending on their weight. That really depends on their ballistic coefficient, or in simple terms, how slippery a bullet is in the air. A longer and more slender but heavier bullet may have less velocity loss down range than a lighter one that’s faster at the muzzle but less aerodynamic over its entire flight path. In the velocity chart above you can see that while the 6.5mm Creedmoor doesn't start the fastest, it's winning the velocity game when you get out past 600 yards.

Muzzle

300

600

1000

American Eagle AR223 55-grain .223 Remington

1,023

453

183

93

Norma Match-223 77-grain .223 Remington

1,045

564

290

158

American Eagle Open Tip Match 140-grain 6.5mm Creedmoor

2,035

1,330

836

450

Sig Sauer Open Tip Match 168-grain .308 Winchester

2,239

1,292

700

375

AR15 vs AR10 Bullet Drop

Gravity is gravity, and as some apple-eating guy figured out, weight doesn’t matter either. If you remove air resistance from the equation, a feather and brick will drop to the ground at the same rate of speed. So when it comes to bullet drop, projectile weight doesn’t matter. What does matter is the time that a given bullet is exposed to the forces of gravity over a certain distance. If one bullet makes it to the 1,000-yard mark faster than another, then it’s exposed to gravity for less time and will drop less. As we saw in a previous chart, higher velocity at the muzzle doesn’t necessarily mean that a speed advantage will carry down range. An aerodynamic bullet can start slower than another but finish faster because it carries it’s velocity over distance more effectively.

For all the loads shown here, we zeroed the rifle at 100 yards and used an optic with a crosshair 2.8 inches above the bore.

Muzzle

300

600

1000

American Eagle AR223 55-grain .223 Remington

-2.8

-12.26

-112.54

-602.27

Norma Match-223 77-grain .223 Remington

-2.8

-16.84

-129.63

-592.06

American Eagle Open Tip Match 140-grain 6.5mm Creedmoor

-2.8

-13.63

-99.04

-408.95

Sig Sauer Open Tip Match 168-grain .308 Winchester

-2.8

-16.48

-123.64

-549.49

Shaquille O'Neals
Shaquille O'Seals

Ponder those figures for just a second. At 1,000 yards, there is a 16-foot difference between the 6.5mm Creedmoor AR-10 and a standard AR-15.

That's over two Shaquille O'Neals tall.

Wind

To keep things simple, let’s assume we’re experiencing a 10 mile per hour crosswind coming directly from the three o’clock position. This chart shows how many inches each bullet will blow sideways at varying distances down range.

Muzzle

300

600

1000

American Eagle AR223 55-grain .223 Remington

0

12.42

61.94

200.10

Norma Match-223 77-grain .223 Remington

0

10.73

50.20

158.41

American Eagle Open Tip Match 140-grain 6.5mm Creedmoor

0

6.96

31.14

100.14

Sig Sauer Open Tip Match 168-grain .308 Winchester

0

9.45

44.36

142.50

What about AR recoil?

All good things in life come at a price. So if you want more energy or velocity, your shoulder is going to pay. There’s a whole lot of complex rocket surgery behind measuring recoil, and much of it depends on the velocity curve of the recoil impulse. However, for a rough comparative guideline, we can look at recoil energy. This measurement takes into account the weight of the rifle (we’ll assume eight pounds for all rifles here), the bullet weight, powder charge weight, and velocity. All outputs are in units of foot-pounds.

Recoil Energy

American Eagle AR223 55-grain .223 Remington

2.75

Norma Match-223 77-grain .223 Remington

3.09

American Eagle Open Tip Match 140-grain 6.5mm Creedmoor

10.54

Sig Sauer Open Tip Match 168-grain .308 Winchester

13.54

Bottom line thoughts…

There’s a reason that so many the best AR15 scopes have the same drop compensation markings for .223 and .308. While not identical and subject to variance depending on bullet types and weights, the trajectories between the two calibers are fairly similar. If you simply want more the energy and momentum of a bigger and fatter bullet, then an AR-10 in the classic .308 caliber might be your Huckleberry.

Where things start to get interesting is with other caliber options presented by the larger magazine well and upper receiver components of the AR-10 rifle platform vs the AR15. With a structure designed to handle longer and fatter cartridges safely, all sort of possibilities open up. While there are others, 6.5mm Creedmoor is a great example. Perhaps that’s why we’re seeing so many AR-10 and other semi-automatic platforms adopting that caliber.


Tom McHale

About Tom McHale

Tom McHale is the author of the Practical Guides book series that guides new and experienced shooters alike in a fun, approachable, and practical way. His books are available in print and eBook format on Amazon. You can also find him on Facebook, Twitter, Instagram and Pinterest.
